Product Highlights
- Thermal Resolution (pixels): 640 × 512
- Pixel Pitch (µm): 12
- NETD (mK): <18
- Base Magnification (x): 2
The new SLIM series from Nocpix provides the best value and features in a compact optic. Focused on versatility and ease of use, SLIM models can be used as either a handheld monocular or a weapon sight. With the included proprietary quick-detach mounting system a hunter can quickly scan and then re-attach the optic to the rifle while maintaining zero. A magnesium alloy body and quiet, soft-touch buttons provide excellent ergonomics in both handheld and weapon-mounted configurations. The included IRB-2 batteries (flay-top 18650 style cell) are easy to swap–letting you stay out longer with the ability to charge through the optic using a magnetic cable. Generous eye relief and a 1024×768 AMOLED display provide a comfortable and highly detailed viewing and hunting experience.
| Thermal Sensor | Sensor Type | Nocpix 640 |
| Resolution (pixels) | 640 × 512 | |
| Pixel Pitch (µm) | 12 | |
| NETD (mK) | < 18 | |
| Frame Rate (Hz) | 50 | |
| Detection Range (y) | 1,750 | |
| Optics | Objective Lens (mm) | 35 |
| Base Magnification (x) | 2 | |
| Digital Zoom (x) | 4 | |
| Field of View (HxV) @ 100m (degrees / m) | 12.6 × 9.4 | |
| Eye relief (mm) | 48 | |
| Rangefinder | Rangefinder Type | N/A |
| Maximum Measuring Range (y) | N/A | |
| Measurement Accuracy (y) | N/A | |
| Display | Display Type | AMOLED |
| Display Resolution (pixels) | 1024 × 768 | |
| Audio/Video | Audio Recording Capable | Yes |
| Video Recording Capable | Yes | |
| Built-in Memory (GB) | 32 | |
| Wi-Fi | Wireless Protocol | Yes |
| Environmental Characteristics |
Degree of Protection (IP Code) | IP67 |
| Operating Temperature Range (°F) | -4 to 122 | |
| Power Supply | Battery Type | 18650 |
| Operating Time on Battery Pack (hr) | 4+ | |
| External Power Supply (V) | USB-C | |
| Weight & Size | Dimensions (inch) | 8.5 × 2.99 × 1.81 |
| Weight (lb) | 1.2 |
